도트,라인,크로스 프로젝션 레이져
| Wavelength | 635nm, 655nm, 785nm, 850nm, 905nm |
| Optical Output Power | <10mW |
| Beam Diameter | Focusable type |
| Beam Divergence | Focusable type |
| Beam Pattern | Dot, Line (5˚, 20˚, 50˚, 90˚), Cross (15˚, 45˚) |
| Input Voltage | DC 3V, DC 5V |
| Operating Current | <100mA |
| Operating Temperature | -10~ +50℃ (Case Tem.) |
| Storage Temperature | -30~ +80℃ |
| Housing Material | Aluminum |
| Wavelength | 635nm, 660nm, 685nm, 785nm, 850nm, 905nm |
| Optical Output Power | <50mW (파장에 따라 최대 광출력 차이있음) |
| Beam Diameter | Focusable type |
| Beam Pattern | Dot, Line (5˚, 15˚, 20˚, 30˚, 45˚, 50˚, 90˚), Cross (15˚, 45˚) |
| Input Voltage | DC 3V, DC 5V |
| Operating Current | <200mA |
| Operating Temperature | -10~ +40℃ (Case Tem.) |
| Storage Temperature | -30~ +80℃ |
| Housing Material | Aluminum |
| Wavelength | 405nm, 4500nm, 520nm, 640nm, 660nm, 808nm |
| Optical Output Power | <50mW (파장에 따라 최대 광출력 차이있음) |
| Beam Diameter | Focusable type |
| Beam Pattern | Dot, Line (5˚, 15˚,20˚, 30˚, 45˚, 50˚, 90˚), Cross (15˚, 45˚) |
| Input Voltage | DC 3V, DC 5V, DC12V |
| Operating Current | <500mA |
| Operating Temperature | -10~ +40℃ (Case Tem.) |
| Storage Temperature | -30~ +80℃ |
| Housing Material | Aluminum |
